Pump Installation And Applications
VM series clean-water submersible pump is the most extensively used pump
suitable for arable land irrigation,mine water drainage,as well as for flood control
campaign,It is compactness in construction,tightness in sealing quality,high
efficiency in energy-conservation,and long durability for use as well.It is suitable
for river,lake and well etc.Technical Date
Suitable fluids
Clean water
Fluid temperature range 0～40℃
Max.working pressure 8bar
Power
Single phase 220V±5%/50HZ Motor
Degree of protection IP68
Insulation class B
Insulation 回
Construction Materials
Pump body aluminium
Motor body aluminium
Impeller rubber
Shaft 45# Steel Accessories
Rope,Impeller,Clap,Check-valve |
|
