SPA4-15/2-0.6F
|
| |
| |
CONDITION OF USAGE:
1. maximum operating depth 5m below water level
2. maximum fluid temperature 40℃
3. PH value in water:6.5-8.5
4. maximum passage for suspended solids￠0.2mm
FUNCTION AND FEATURE:
With features of compact size, light weight, and convenient use, this pump is widely used for farming, breed aquatics, mining, and construction site. The float switch can automatically control on and off with the change of the liquid level. Protector inside the motor can automatically cut off the power when overheating or overloading, to guarantee pump’s security and reliability under hard environment(three phase is available at request).
|
|
|
| |
|
| |
|
| |
| MODEL |
INPUT
POWER |
VOLTAGE |
MAX.FLOW
|
MAX.HEAD
|
INLET/
OUTLET |
GW |
PACKING
DIMENSION |
| SPA4-15/2-0.6F |
0.6KW |
220V/50Hz |
75L/min |
27m |
OUTLET:25mm |
18.5kg |
27.0x23.5x50.0cm |
|
|
