SPA4-15/2-0.6F

CONDITION OF USAGE:
1. maximum operating depth 5m below water level
2. maximum fluid temperature 40
3. PH value in water:6.5-8.5
4. maximum passage for suspended solids0.2mm
FUNCTION AND FEATURE:
With features of compact size, light weight, and convenient use, this pump is widely used for farming, breed aquatics, mining, and construction site. The float switch can automatically control on and off with the change of the liquid level. Protector inside the motor can automatically cut off the power when overheating or overloading, to guarantee pumps security and reliability under hard environment(three phase is available at request).



MODEL INPUT POWER VOLTAGE MAX.FLOW
MAX.HEAD
INLET/
OUTLET
GW PACKING DIMENSION
SPA4-15/2-0.6F 0.6KW 220V/50Hz 75L/min 27m OUTLET:25mm 18.5kg 27.0x23.5x50.0cm
