JSW

The JSW series are injection type clean water pumps, which are composed of a centrifugal pump and a nozzle, have the advantages of beautiful design, self-priming in short time, reliable performance, high head and deep suction. They are suitable for pumping clean water and non-aggressive liquid. They are particularly suitable for domestic applications such as supply water from well, pool etc, the automatic distribution of water by surge tanks and pressure switch, gardening, and pressure boosting etc.
Pumps should be installed in a covered area, protected against the weather.

Operating Limiations
Max ambient temperature up to 40¡æ
Max fluid temperature up to 40¡æ
Max pressure up to 10 bar

Construction Features
Pump Body: cast iron
Motor Housing: aluminum
Shaft: 45#steel /stainless steel
Impeller: brass/plastic
Motor: closed, externally ventilated
Insulation Class: B/F
Protection Class: IP44/IP54
Duty: continuously rated
Mechanical Seal: ceramic steatite/ metalized carbon




MODEL INPUT POWER VOLTAGE MAX.FLOW
MAX.HEAD
INLET/
OUTLET
GW PACKING DIMENSION
JSW10M 0.75KW 220V/50HZ 80L/min 34m 1"/1" 15.6kg 420x205x235mm
JSW10H 0.75KW 220V/50HZ 70L/min 42m 1"/1" 15.6kg 420x205x235mm
JSW15M 1.1KW 220V/50HZ 85L/min 45m 1"/1" 16.8kg 420x205x235mm
JSW15H 1.1KW 220V/50HZ 80L/min 50m 1"/1" 16.8kg 420x205x235mm
