JETLB

The JETLB series are injection type clean water pumps, which are composed of a centrifugal pump and a nozzle, have the advantages of beautiful design, self-priming in short time, reliable performance, high head and deep suction. They are suitable for pumping clean water and non-aggressive liquid. They are particularly suitable for domestic applications such as supply water from well, pool etc, the automatic distribution of water by surge tanks and pressure switch, gardening, and pressure boosting etc.
Pumps should be installed in a covered area, protected against the weather.

Operating Limitations
Max ambient temperature up to 40
Max fluid temperature up to 40
Max pressure up to 10 bar

Construction Features
Pump Body: cast iron
Motor Housing: aluminum
Shaft: 45#steel /stainless steel
Impeller: brass/plastic
Motor: closed, externally ventilated
Insulation Class: B/F
Protection Class: IP44/IP54
Duty: continuously rated
Mechanical Seal: ceramic steatite/ metalized carbon




MODEL INPUT POWER VOLTAGE MAX.FLOW
MAX.HEAD
INLET/
OUTLET
GW PACKING DIMENSION
JET60LB 0.37KW 220V/50HZ 42L/min 38m 1"/1" 14.3kg 445x205x205mm
JET80LB 0.55KW 220V/50HZ 48L/min 46m 1"/1" 17.5kg 450x205x230mm
JET100LB 0.75KW 220V/50HZ 54L/min 52m 1"/1" 18.5kg 450x205x230mm
