CPM128

The CPM series pumps are high-efficient, power-saving and compact in structure, convenient to operate and maintain . The hydraulic characteristic is with high head and small capacity. They are suitable for both domestic and industrial applications to convey clean water and non-aggressive chemical liquid, also can be applied to supply the water for
garden, hotel, villas and agricultural irrigation, etc.
Pumps should be installed in a covered area, protected against the weather.

Operating Limitations
Max ambient temperature up to 40
Max fluid temperature up to 80
Max pressure up to 10 bar

Construction Features
Pump Body: cast iron
Motor Housing: aluminum
Shaft:45#steel /stainless steel
Impeller: brass
Motor: closed, externally ventilated
Insulation Class: B/F
Protection Class: IP44 /IP54
Duty: continuously rated
Mechanical Seal: ceramic steatite/ metalized carbon




MODEL INPUT POWER VOLTAGE MAX.FLOW
MAX.HEAD
INLET/
OUTLET
GW PACKING DIMENSION
CPM128 0.37kw 220V/50HZ 90L/MIN 22m 1"*1" 9.3kg 275mm*195mm*245mm
CPM146 0.55KW 220V/50HZ 100L/MIN 28M 1"*1" 12.3KG 310mm*195mm*250mm
CPM158 0.75KW 220V/50HZ 110L/MIN 34M 1"*1" 14.3KG 320mm*215mm*275mm
CPM180 1.1KW 220V/50HZ 120L/MIN 42M 1"*1" 21.8KG 360mm*235mm*300mm
CPM200 1.5KW 220V/50HZ 130L/MIN 47M 1"*1" 24KG 365mm*255mm*320mm
