SPA3-18-0.55 SPA6-18-0.75 SPA3-24-0.75


CONDITION OF USAGE:
1. The depth for the electrical pump below the water is no more than 5m
2. The temperature of the water is no higher of 40C
3. The PH figure of the water is between 6.5-8.5
4. The grain diameter of the solids in the water is no bigger than 0.2mm


FUNCTION AND FEATURE:
This model of pump is characterized with high lift, compact size, light weight and convenient use and vastly used in high-position water delivery, flush and places as construction sites. The 3-phase motor pump has a more stable function. The float switch can automatically control on and off with the change of the liquor level. The protector in the motor can automatically cut off the power when it overheated or overcurrented, thus guaranteee the security and reliability of pump's operation even in the atrocious environment.




MODEL INPUT POWER VOLTAGE MAX.FLOW
MAX.HEAD
INLET/
OUTLET
GW PACKING DIMENSION
SPA3-18-0.55 0.55kw 220V/50Hz 108L/min 21m 40,32,25mm 12.3kg 25.0x22.0x42.5cm
SPA6-18-0.75 0.75kw 220V/50Hz 265L/min 21m 40,32,25mm 16kg 27.0x23.5x42.0cm
SPA3-24-0.75 0.75kw 220V/50Hz 100L/min 26m 40,32,25mm 16kg 27.0x23.5x42.0cm
