SPA6-28/2-1.1AF SPA6-39/3-1.5AF


CONDITION OF USAGE:
1. The depth for the electrical pump below the water is no more than 5m
2. The temperature of the water is no higher of 40C
3. The PH figure of the water is between 6.5-8.5
4. The grain diameter of the solids in the water is no bigger than 0.2mm


FUNCTION AND FEATURE:
This model of pump is characterized with high lift, compact size, light weight and convenient use and vastly used in high-position water delivery, flush and places as construction sites. The 3-phase motor pump has a more stable function. The float switch can automatically control on and off with the change of the liquor level. The protector in the motor can automatically cut off the power when it overheated or overcurrented, thus guaranteee the security and reliability of pump's operation even in the atrocious environment.




MODEL INPUT POWER VOLTAGE MAX.FLOW
MAX.HEAD
INLET/
OUTLET
GW PACKING DIMENSION
SPA6-28/2-1.1AF 1.1kw 220V/50Hz 250L/min 30m 50mm 23.5kg 27.5x22.5x53.0cm
SPA6-39/3-1.5AF 1.5kw 220V/50Hz 240L/min 42m 50mm 27.6kg 63.0x29.5x21.5cm
