SPA-1100


CONDITION OF USAGE:
1. The depth for the electrical pump below the water is no more than 5m
2. The temperature of the water is no higher of 40C
3. The PH figure of the water is between 6.5-8.5
4. The grain diameter of the solids in the water is no bigger than 0.2mm


FUNCTION AND FEATURE:
Model SPA standing submersible pump is vastly used for farming, breed aquatics, mine enterprise and construction site. It features its compact size, light weight, and convenient use. (Also can be assembled with 3-phase motor). THe float switch can automatically control on and off with the cahnge of the liquor level. The protector in the motor can automatically cut off the power when it overheated or overcurrented, thus guaranteee the security and reliability of pump's operation even inthe atrocious environment










MODEL INPUT POWER VOLTAGE MAX.FLOW
MAX.HEAD
INLET/
OUTLET
GW PACKING DIMENSION
SPA-1100 1.1kw 220V/50Hz 580L/min 9m 80mm 20.5kg 45.0x31.5x24.5cm
