V2200


CONDITION OF USAGE
1. The maximum deep it is allowed in water is 5m from its center of impeller:
2. The trans medium's temperature shouldn't be higher than 40C
3. Trans medium's PH: 4-10
4. Kinematics viscosity of the trnas mediumis: 7x10-7~23x10-6 m2/s;
5. Density of the trans medium limit: 1200kg/m3


FUNCTION AND FEATURE:
This advanced Vseries, a branch of single-phase and three-phase drainage pumps, will be your ideal drainage helper. It can work safely and efficiently at high flux with the feature of complete heads. The design is designed to a wide tunnel which helps to convey the long fiber liquid or the solid whose diameter is about 20mm or the long fiber liquid(you need to change its filter net). The selection of bottom suction structure, stainless steel and special cast iron made the pump has the capabilities of complete drain and high resistance special cast iron made the pump has the capabilities fo complete drain and high resistance of abrasion and corrosion. The floast switch can automatically control on and off with the chagne of the liquor level. The protector in the motor can automatically cut off the power when it overheated or overcurrrented thus guarantee the security and reiliability of pump's run even in the atrocious environment.




MODEL INPUT POWER VOLTAGE MAX.FLOW
MAX.HEAD
INLET/
OUTLET
GW PACKING DIMENSION
V2200 2.2kw 220V/50Hz 700L/min 17m 80mm 35kg 59.0x35.0x25.0cm
