V450 V750


CONDITION OF USAGE:
1. The maximum deep it is allowed in water is 5m from its center of impeller:
2. The trans medium's temperature shouldn't be higher than 40C
3. Trans medium's PH: 4-10
4. Kinematics viscosity of the trans mediumis: 7x10-7~23x10-6 m2/s;
5. Density of the trans medium limit: 1200 kg/m3


FUNCTION AND FEATURE:
This advanced V series, a branch of single-phase and three-phase drainage pumps, will be your ideal drainage helper. It can work safely and efficiently at high flux with the feature of complete heads. The design is designed to a wide tunnel which helps to convey the long fiber liquid or the solid whose diameter is about 25mm. The selection of bottom suction structure, stainless steel and special cast iron made the pump has the capabilities of complete drain and high resistance special cast iron made the pump has the capabilities fo complete drain and high resistance of abrasion and corrosion. The floast switch can automatically control on and off with the chagne of the liquor level. The protector in the motor can automatically cut off the power when it overheated or overcurrrented thus guarantee the security and reiliability of pump's run even in the atrocious environment.




MODEL INPUT POWER VOLTAGE MAX.FLOW
MAX.HEAD
INLET/
OUTLET
GW PACKING DIMENSION
V450 0.45kw 220V/50Hz 200L/min 8.5m 50mm 18.5kg 26.0X19.5X50.0cm
V750 0.75kw 220V/50Hz 300L/min 12m 50mm 19.5kg 26.0X19.5X54.0cm
